Demo Unit aus unserem Shop mit leichten Spuren am Gehäuse.
Eines der schnellsten Thunderbolt Audio Interfaces auf dem Markt. Speziell für Plugins ala Bias oder andere eines der wenigen mit dehnen man wirklich direkt spielen kann.
Speziell die Burr Brown PCM4202 leisten einen hohen Beitrag zum guten Sound des TAC 2R.
Durch die Bus-Powered Technik des TAC 2 natürlich ideal für alle die mobil ohne Netzteil recorden wollen.
Zudem hat es auch noch Midi In/ Out
The compact, rugged TAC-2R audio interface uses the latest Thunderbolt™ technology for blazingly fast speed, near zero latency and the ultimate in high-quality audio, up to 24-bit/192 kHz. With its easy-to-use design and advanced converters, the TAC-2R is perfect for studio and field recording of mics and instruments, onstage playback, and pristine audio streaming. It can even serve as an ultra-stable MIDI interface.
FEATURE LIST
- 2-in/2-out high speed Thunderbolt™ audio interface
- Support for recording and playback up to 24-bit/192 kHz
- Ultra-low latency audio streaming
- Two combo balanced XLR/TRS input connectors accept both mic- and line-level signal
- Hi-Z switches allow direct connection of electric guitar or bass
- Switchable +48V phantom power
- Two balanced TRS output jacks for connection to amplifiers or self-powered speakers
- ¼” headphone jack with dedicated level control
- Independent gain controls and clip LEDs for each input
- Large knob output volume control
- Direct Monitoring switch for zero latency monitoring in mono or stereo
- MIDI In and Out
- High-performance mic preamps with up to +60 dB of amplification
- 4x upsampling during A/D and D/A conversion for reduced noise and enhanced fidelity
- Asynchronous transfer system unaffected by computer jitter
- Bus powered—no AC power required
- Robust metal housing ensures roadworthiness
- Works with all Thunderbolt-equipped Macintosh computers running OS X 10.9.5 or later
SPEZIFIKATIONEN
INPUTS
| INPUT 1/2 CONNECTORS: |
XLR/TRS combo jacks (XLR: 2 hot / TRS: TIP hot) |
| INPUT GAIN: |
0 to 60dB in 1dB steps |
| INPUT IMPEDANCE: |
5kΩ (1 MΩ (when Hi-Z ON) |
| MAXIMUM INPUT LEVEL: |
+12 dBu (@0dBFs) |
| PHANTOM POWER: |
+48V |
L/R OUTPUT
| TYPE: |
1/4″ TRS phone jack (Balanced) |
| MAXIMUM OUTPUT LEVEL: |
+14 dBu (@0dBFs) |
| OUTPUT IMPEDANCE: |
100Ω |
PHONES OUTPUT
| TYPE: |
1/4″ stereo phone jack 20mW + 20mW (into 32Ω load) |
| MAXIMUM OUTPUT LEVEL: |
+8 dBu (@0dBFs) |
| OUTPUT IMPEDANCE: |
33Ω |
AD/DA CONVERSION
| TYPE: |
4x upsampling ( at 44.1kHz or 48kHz) |
| CHIPSET: |
Burr Brown PCM4202 (A/D) AKM AK4396 (D/A) |
| FREQUENCY RESPONSE: |
-1.0 dB: 20 Hz – 60 kHz @ 192kHz -1.0 dB: 20 Hz – 40 kHz @ 96kHz-1.0 dB: 20 Hz – 20 kHz @ 44.1kHz |
| A/D DYNAMIC RANGE: |
118dB typical (IHF-A) |
| D/A DYNAMIC RANGE: |
120dB typical (IHF-A) |
OTHER
| AUDIO CHANNELS (RECORDING): |
2 |
| AUDIO CHANNELS (PLAYBACK): |
2 |
| S/N RATIO EIN: |
-125dBu (IHF-A) @ 60dB, 150Ω input |
| SAMPLING FREQUENCY: |
192kHz, 176.4kHz, 96kHz, 88.2kHz, 48kHz, 44.1kHz |
| BIT DEPTH: |
24-bit |
| LATENCY (TYPICAL): |
4.17 msec round trip (@ 44.1kHz sampling / 64 sample buffer size) |
| INTERFACE: |
Thunderbolt |
| POWER: |
Thunderbolt Bus Power |
| POWER CONSUMPTION: |
10 W maximum |
| DIMENSIONS: |
113.9mm(D) x 176.0mm(W) x 46.2mm (H) |
| WEIGHT: |
714g |
|
*0dBu＝0.775Vrms |
MIDI
| MIDI INPUT: |
5-pin DIN jack |
| MIDI OUTPUT: |
5-pin DIN jack |
