Specs:
Body:Alder (back)
Top:Flamed Maple 5A Custom Shop
Neck heel:Special contoured for easy upper frets access
Unique Features:Slightly slanted body top on both sides
Back belly cut
Binding:3-ply ABS binding (Ivory/Black/White)
Construction:Set-in
Scale:25.4″ (645mm)
Neck:5-ply / Maple-Mahogany
Radius:16″ (406 mm)
Fingerboard:Rosewood / Pau Ferro *
* – Smooth transition starting from 2017 – after new CITES regulations.
Hard Rock Maple
3-ply ABS binding (Ivory/Black/White)
Markers & Inlays:Plain, no markers + side dots
Neck dimensions:Width at nut – 43 mm
Width XII fret – 51 mm
Width XXII fret – 56 mm
Thickness I fret – 20.5 mm
Thickness XII fret – 21.5 mm
Truss rod:Double action truss rod
Model’s name inscripted in the trussrod cover
Frets:22 jumbo, Ferd Wagner 9665, 18% N/S Hard
Crown dimensions: 2.64 × 1.20 mm (w × h)
Headstock:Angled; topped with chosen body wood
3-ply ABS binding (Ivory/Black/White)
Body matching finish
Nut:Graph Tech Black TUSQ
Tuners layout:3 + 3
Pickups / Electronics:
Bare Knuckles
Control:1 × Volume + 1 × Tone
3-way lever pickup switch (S-S or H-S configuration)
Knobs:Standard metal dome knob(-s)
Pickguard:3-ply / White
Bridge:Mayo Vintage Tele Guitar Bridge / Strings-thru-body
Strings:Daddario – NYXL .010 – .46 [6-string]
Tuners:Schaller M6 Locking
Additional equipment:
Schaller Security Straplocks
Switchcraft jack
Hardware colour:
Chrome (CR)
Bag / case:
Hardshell case
