CONNECT 2 ist das benutzerfreundlichste Audiointerface für Musik- und Contentproduktion. Es kombiniert geniale Usability, leistungsstarke Funktionen und unglaubliche technische Spezifikationen.
Kommt mit CONTROL CENTER Software und einfach zu bedienenden Tools, die dir mit nur wenigen Klicks sensationellen Sound liefern.
- USB-C Audiointerface
- Sensationeller Sound mit wenigen Klicks via Autosetup
- Touch-basierte und intuitive Bedienung
- Clipguard schützt dein Signal vor Clipping
- Single-Klick Compressor und Denoiser
- Drei charakteristische Preamp Sounds
- Custom Taste für Workflow Shortcuts
- Individuelle LED-Farben und Helligkeit
Specs:
Device Features RGBW LEDs, MUTE, custom button, autogain, input / playback mix, gain reduction display, Kensington lock Control Capacitive touch Inputs 1x Microphone: balanced 3-pin XLR, 1x Instrument: Hi-Z 6,3 mm jack Outputs 2x Speaker: 6,3 mm balanced jack, 1x Headphone: 6,3 mm jack, 1x Headphone: 3,5 mm jack Metering 25 step high-resolution Dimensions and weight 151 x 110 x 41 mm, 394 g Power requirements USB bus-powered Digital Typ USB-C audio interface Software LEWITT CONTROL CENTER DAW included Steinberg Cubase LE, Cubasis LE Compatibility MacOS, Windows, iOS (plug and play with USB-C devices, devices with lightning connector require Camera Connection Kit and external bus power) ASIO driver Yes Abtastrate 44,1 kHz, 48 kHz, 96 kHz Bit rate 24 USB Audio Class 2,0 Signal flow Input / playback mix DSP powered Yes Loopback Yes Inputs / Outputs 4 (includes 2 software channels) / 2 Streaming modes macOS mode, mobile mode Min. Systemanforderungen Windows 10 (64-Bit): 4GB RAM Minimum, USB 2.0 Anschluss, macOS 10.15 oder höher: 4GB RAM Minimum, USB 2.0 Anschluss Microphone Input Features DSP (low-cut filter, clipguard, preamp modes, denoise, compressor, autogain, autosetup) Typ balanced Anschluss 3-pin XLR Phantom power 48 V Gain range 0 – 72 dB Equivalent input noise –129 dBV (A) Dynamikumfang 118 dB (A) – Without clipguard 118 dB (A) Max input level 15,8 dBV Total harmonic distortion 0,001% Frequenzumfang 20 Hz – 20 kHz (± 0,1 dB) Instrument Input Features DSP (low-cut filter, clipguard, preamp modes, denoise, compressor, autogain, autosetup) Typ Hi-Z, differential ground loop break circuit Anschluss 6,3 mm jack Gain range 0 – 60 dB Input impedance 2,5 M Ω Equivalent input noise –108 dBV (A) Dynamikumfang 121 dB (A) – Without clipguard 105 dB (A) Max input level 12,5 dBV Total harmonic distortion 0,0008% Frequenzumfang 20 Hz – 20 kHz (± 0,1 dB) Speaker Output Features High volume speaker mode, Mute, Volume, Map system volume controls Anschluss 2x 6,3 mm jack, balanced Frequenzumfang 20 Hz – 20 kHz (± 0,1 dB) Max output level 12,2 dBV (high volume mode) Total harmonic distortion 0,0023% Impedance 200Ω Headphone Output Features High impedance headphone mode, Mute, Volume, Map system volume controls Anschluss 1x 6,3 mm jack, stereo, 1x 3,5 mm jack, stereo Frequenzumfang 20 Hz – 20 kHz (± 0,2 dB) Max output level 6,8 dBV (high impedance mode) Total harmonic distortion 0,003% Impedance 1,9 Ω
